The tool inspection instrument is an ideal tool inspection tool with a high-resolution CCD B/W camera (used for non-contact surface light and transmitted light measurement of tool edges, and surface light measurement of tool head geometry).

Features: 1. The guide rail is directly fixed on the marble to ensure the pitch and yaw accuracy of the guide rail operation. 2. The light source, belt traction, and optical ruler are separated independently to reduce mutual influence. 3. The central traction of the belt ensures the balance and smoothness of the transmission. 4. The arched design of the crossbeam enhances the rigidity of the X-axis crossbeam, while the integrated design of the Z-axis makes it easily compatible with conventional functions such as 40 phase lights and lasers. 6. The control cabinet is designed to be integrated with the machine body, reducing the length of the machine's wiring. 7. Marble is measured in length, width, and thickness according to measuring standards to ensure the most basic accuracy. 8. The head cover is designed to be separated and can be flipped open for easy maintenance and repair. Additionally, a deceleration position switch is added to prevent the machine from colliding with the limit. 10. Integrated design of limit deceleration circuit board for easy installation and debugging. 11. Main control circuit design, adding machine status display for easy monitoring of machine status. 12. The motor power line and coding line are separated and routed to reduce internal circuit interference. 13. Control cabinet with strong and weak current separation, strong current section, multi-stage filtering, and overvoltage and overcurrent protection. 14. Key switch, emergency stop switch, and handling methods for emergency situations. 15. Use OVM Pro 2.0 software.
